55294, Amana Carbide Tipped 82-Deg Countersink w/ Adjustable Low Friction Depth Stop, 3/8″ Dia x 1/8″ Drill Dia x 1/4″ Quick Release Hex Shank
Low friction polymer collar. No surface scratches or burn marks!
These tools combine carbide countersink, high-speed-steel drill bit and free-spinning, low friction depth-stop. The countersink leaves a clean hole edge and the adjustable depth-stop doesnt mar the surface. The large openings around the collar allow the chips to clear effectively and eliminate clogging.
Quick release 1/4″ hex shank with slow spiral, HSSM2 fully ground drill bit included.
Excellent for Drilling:
- Natural Woods
- Man-Made Boards
- MDF
- Chipboard
- Plywood
- Aluminum/Non-Ferrous
- Aluminum Composite Material (ACM)
- Composites
- Composite Decking Materials
Warning:When drilling aluminum/non-ferrous materials, for optimal results and extended tool life use lubricant or air cooling. Make sure the material is fixed and drill is stable during drilling.
Specifications:
| (a) Angle | 49 |
|---|---|
| (B) Cutting Height | 9mm |
| (D) Diameter | 3/8 |
| (d) Shank | 1/4 |
| Overall Length (L) | 2-3/8 |
| Drill Din | 1897 |
| Wood Screw Size | 6 |
| D1 | 1/8 |
| Replacement Drill | 630-226 |
